Adaptable chainstay lengths on large/XL bikes for a fully balanced feel on the trail, while rider size-appropriate front triangle enhances overall stability and handling.

• • 435mm on S - M
  • 440mm on L
  • 445mm on XL

29 x 2.6'' Maximum tire clearance

Super Boost rear spacing provides massive tire clearance at 29x2.6 for capable mud ejection plus the traction you want when trails turn slick.

Cable holder / shock washer combo

User-friendly cable holder doubles as a lower shock washer for ultra-easy reassembly.

Rear pivot brake cable clip

Rear pivot brake cable clip complements streamlined architecture and shuns frame rubbing.

Double row linkage bearings

Double-row, double-lip sealed linkage bearings for precision movement and superior longevity.

2 bolts ISCG mount

Get-gnarly chain guide fortified for on-trail use and abuse.

Molded Polyurethane protector

High-density rock guard and chain stay protecor enhance durability for the rugged ride ahead.

Updated Geometry

Modern trail bike geometry featuring a 15mm longer reach and 1 degree slacker head angle for confidently tackling technical sections, while steeper seat tube angle helps you motor up the climbs.

Geo adjust Flip Chip

Switch between Hi/Lo mode to customize ride characteristics. The flip chip is conveniently located at the base of the shock mount with less moving parts, meaning it's easier to use, especially if you want to conduct some on-trail experiments.

Lifetime warranty

Riding passions last a lifetime. Now your bike does too.

Threaded BB

Threaded BB for headache-free removal and easy maintenance.

Slimmer Rear End

New hardware makes the rear-end 9.5mm slimmer, improving clearance without affecting performance or bearing longevity.

34.9 seat post

Using bigger dropper stanchion for added longevity and reduced post flex.

• • Insertion length:
    • S: 240mm
    • M: 250mm
    • L: 280mm
    • XL: 280mm

• • Post Compatibility:
    • S: 150 M: 175 L: 200 XL :200
